Name: 19 Seats Diesel Engine Coaster Buses with Leaf Spring Suspension and Front Mounted Engine for 100km/h Top Speed
Brand: Zhongzhi First Bus Chengdu Co., Ltd.
SKU: CDL6606LFDF
Price: 15,350.00 USD
Availability: InStock

Home > Products > Coaster Buses >

19 Seats Diesel Engine Coaster Buses with Leaf Spring Suspension and Front Mounted Engine for 100km/h Top Speed

Cummins Diesel Engine Coaster Buses

19 Seats Coaster Buses

Leaf Spring Front Engine Buses

Place of Origin:

Chengdu, China

Brand Name:

ZEVAUTO

Certification:

ISO

Model Number:

CDL6606LFDF

Request A Quote

Product Details

Product Name:

Coaster Buses

Vehicle Size (mm):

5990x2025x2635

Seats:

19 Seats

Wheel Base (mm):

3200

Front/Rear Overhang:

1135/1655

Approach/Departure(º):

17.5/13

Top Speed (km/h):

100km/h

Curb Weight (kg):

3500

Gross Weight (kg):

4990

Engine Position:

Front Mounted Engine

Engine Displacement:

2.982L

Transmission:

Manual 5 Speed

Suspension:

Leaf Spring

Tyre:

215/75R16-10PR Steel Rim

Highlight:

Cummins Diesel Engine Coaster Buses

19 Seats Coaster Buses

Leaf Spring Front Engine Buses

Payment & Shipping Terms

Minimum Order Quantity

Packaging Details

nude packing

Delivery Time

25 working days

Payment Terms

T/T

Supply Ability

25000 units/per year

19 Seats Leaf Spring Air Conditioned Coaster Bus for Business and Commuter Transport

Get Best Price

video

6m Length 19 Seat Diesel Coaster Bus Minibus With Air Conditioner

Get Best Price

video

6m Diesel Coaster Bus with 19 Seats Euro 4 and Manual 5 Speed Transmission

Get Best Price

video

19 Seats Diesel Engine Coaster Buses with Leaf Spring Suspension and Front Mounted Engine for 100km/h Top Speed

Get Best Price

+8613608032908

jolin@zevauto.com

Contact Now

Product Description

6m 19 Seats Diesel Engine Coaster Buses

Professional 19-seat diesel coaster buses with leaf spring front engine, designed for reliable transportation solutions.

Technical Specifications

Overall Parameters

Parameter	Specification
Vehicle Size (mm)	5990x2025x2635
Rated Passenger Capacity	18+1
Wheel Base (mm)	3200
Front/Rear Overhang	1135/1655
Front/Rear Tread	1665/1525
Approach/Departure (°)	17.5/13
Max. Grade-ability (%)	≥20%
Top Speed	100km/h with speed limit device
Curb Weight (kg)	3500
Gross Weight (kg)	4990

Chassis System

Component	Specification
Engine Model	YC4FA115-40 front mounted engine
Engine Displacement	2.982L
Max. Power/Rotating Speed	85KW+5%/3200r/min
Max. Torque/Rotating Speed	300N.m+6%/1600～2400r/min
Transmission	Manual 5 speed
Clutch	Single diaphragm spring
Suspension	Leaf spring
Steering	Integral power steering
Braking	Front disc and rear drum; dual circuit air brake, ABS, auto slack adjuster
Tyre	215/75R16-10PR steel rim

Electronic Systems

Component	Specification
A/C	12000kcal/h Built-in cold air conditioner
Defrosting	Air blow defroster
Windscreen Wiper	Dual speed with scrubber
Instrument	Bus instrument, Coaster dashboard
Audio-system	MP3, radio
Battery	Maintenance-free

Body Features

Feature	Specification
Body Frame	Stamping body
Passenger Door	Pneumatic out swing door
Window Glass	Sealed window except for copilot position and the last row
Driver Seat	Adjustable back rest
Passenger Seat	18 with hand rest, Back rest non-adjustable
Interior	Coaster inner trim
Lights	Front and rear combination light, Fog light, LED day light, Outline marker lamps, high-mount stop lamp, Rectangle inside dome light
Rear-view System	Endoscope, manual reversing mirror, On board monitoring system with 4 cameras, Central monitoring display, Reversing camera
Floor and Floor Cover	Bamboo floor, anti-slippery, flame retardant leather
Roof Hatch	1pcs safety hatch with air vent
Paint	Metallic, light camel yellow

Service & Safety Facilities

Front shade plate, side sunshade at driver window
Standard equipment kit
Triangle warning board
Safety hammer with alarm function
Electronic clock
Reflective vest
Parking leas
Travelling record with GPS
Manual fire distinguisher in passenger area (2*4kg)
Auto fire distinguisher in engine cabin
USB connector at driver area
