12m New Energy Pure Electric Bus With Air Suspension Battery 350.07kwh

12m New Energy Pure Electric Bus With Air Suspension Battery 350.07kwh

12m Pure Electric Bus 350.07 kwh

Pure Electric Bus With Air Suspension

New Energy Bus 350.07 kwh

Place of Origin:

Chengdu, China

Brand Name:

ZEVAUTO

Certification:

ISO

Model Number:

CDL6121URBEV

Contact Us

Request A Quote
Product Details
Passenger Capacity:
94/22-46 Seats
Vehicle Size (mm):
12000*2550*3225
Wheel Base (mm):
6200
Front/Rear Overhang:
2700/3100
Approach/Departure(º):
8/8
Max. Grade-ability(%):
15%
Top Speed (km/h):
69km/h
Curb Weight (kg):
11800
Gross Weight (kg):
18000
Battery:
350.07 Kwh
Driving Range:
280-650km
Suspension:
Air Suspension
Payment & Shipping Terms
Minimum Order Quantity
1
Packaging Details
nude packing
Delivery Time
25 working days
Payment Terms
T/T
Supply Ability
25000 units/per year
Product Description

12 Meter New Energy Pure Electric City Bus With Air Suspension, Battery 350.07kwh

It's an advanced and eco-friendly public transportation vehicle that runs solely on electricity, eliminating harmful emissions and reducing carbon footprint. The air suspension system provides a smooth and comfortable ride by absorbing road bumps and vibrations. With its high-capacity battery, the bus offers an extended range, allowing it to cover longer distances on a single charge. The rechargeable battery can be charged overnight or at designated stations. With a seating capacity to accommodate a significant number of passengers, the bus provides a spacious and comfortable interior. It represents the progress in electric vehicle technology and the growing trend towards sustainable transportation, aiming to reduce pollution and dependence on fossil fuels while providing a cleaner and greener urban commuting solution.

Features:

Pure Electric: This bus operates solely on electric power, meaning it produces zero tailpipe emissions, making it an environmentally friendly transportation option.
Air Suspension: The bus is equipped with an air suspension system, which effectively absorbs road shocks and vibrations, providing a smooth and comfortable ride for passengers.
High-capacity Battery: With a 350.07 kWh battery, the bus has an extended range, allowing it to cover longer distances on a single charge.
Spacious Interior: The bus is designed with ample seating capacity, providing a comfortable and roomy interior for passengers.



Advantages:

Environmental Friendliness: As a pure electric vehicle, the bus contributes to reducing air pollution and greenhouse gas emissions, promoting a cleaner and greener urban environment.
Passenger Comfort: The air suspension system ensures a smooth and comfortable ride, minimizing discomfort from road bumps and vibrations.
Extended Range: The high-capacity battery allows the bus to cover longer distances, reducing the need for frequent recharging and increasing operational efficiency.
Noise Reduction: The electric powertrain of the bus operates silently, significantly reducing noise levels compared to traditional combustion engine buses, providing a quieter and more pleasant commuting experience.
Sustainable Transportation: By eliminating the use of fossil fuels, the bus helps to reduce dependence on non-renewable resources and contributes to sustainable urban transportation.

Specification:


Overall specsPassenger capacity94/22-46 seatsMotor specsManufacturerZEV
Vehicle size (mm)12000*2550*3225Model--
Wheel base (mm)6200Positionrear
Front/Rear overhang2700/3100Engine type--
Front/Rear tread2119/1887Max.power(kw/rpm)240
Approach/Departure(º)8/8Max. torque (N.m/rpm)2800
Max. Grade-ability(%)15%Displacement(L)--
Top speed (km/h)69km/hFuleElectric
Curb weight (kg)11800Emission--
Gross weight (kg)18000
 Battery350.07 kwh,LiFePo4, water cool. with monitoring system.
 Charging holder

Single or Double optional.
Full charging 3.1h single / 1.6h double

 Driving range280-650km
 ItemSpecsRemarks
ChassisFront axle7.5T
Rear axle13T
TransmissionAuto transmission
Suspension

Import air suspension, SACHS shock absorber
ECAS


SteeringBOSCH 8098 steering
BrakingKNORR brake system, disc brake and maintenance free
Tyre275/70R22.5 aluminum rim
BatteryMaintenance-free type 2*195Ah
electronicsAC32000kcal/h with air purifier
DefrosterElectric heater , 4 PTC radiator
InstrumentCAN BUS LINE. LCD instrument
Audio-system2 pcs LCD display
LightsLED combination lights
Monitoring systemCCTV system with 10 cameras
Route boardFront, rear and side LCD screen
 Driver assistance system

ADAS HSA
EPB ASR
ESC CBS
AEBS AutoHold


Bus facilitiesBodyElectro coating.
Passenger doorFront aluminum inner swing door
WindowSliding side window, laminated front windscreen and tempered rear-shield
Passenger seat28 plastic city bus seats with cushion
Interioraluminum-plastic
Floor and floor coverPVC floor, anti-slippery, flame retardant leather
PaintSolid paint
OthersStation broadcaster with speaker, wireless passengers stop buttons, Safety hammer with alarm function,Electronic clock,Manual fire distinguisher ,Auto fire distinguisher in battery cabin,USB connector at driver area, Travelling record with GPS

12m New Energy Pure Electric Bus With Air Suspension Battery 350.07kwh 0


Company:

Zhongzhi first bus chengdu Co.,ltd is a wholly-owned subsidiary of Zhejiang Kangsheng Co., Ltd. It is a leading domestic new energy vehicle brand with comprehensive production capabilities and R&D center. The company focuses on developing, manufacturing, and promoting new energy vehicles. With a registered capital of 438.7075 million RMB and an area of 487,000 square meters, it employs over 500 people, including 160+ engineering and technical professionals. Zhongzhi first bus specializes in hydrogen fuel cell bus, wheel-side drive, and carbon fiber composite materials. It has obtained numerous certifications and nearly 100 national patents. The company follows a hydrogen fuel cell bus+ pure electric dual-drive development path and has established a strong marketing network and after-sales service team. It has expanded nationwide and exports to Southeast Asia, the Middle East, and North Africa, showcasing its "Chengdu-made" intelligent manufacturing capabilities. Zhongzhi first bus Chengdu has been recognized as a National High-tech Enterprise, a pioneer in hydrogen fuel cell bus demonstrations, an exemplary contract-abiding and credit-worthy enterprise, and has won awards in the new energy vehicle industry.
12m New Energy Pure Electric Bus With Air Suspension Battery 350.07kwh 1

FAQ:


Q: Who we are?
A: ZEV is a group company specializing in buses and coaches R&D, manufacturing and marketing. From its foundation in 2000’s, ZEV’s culture of continuous innovation has made it a leading manufacture in China. Now we have developed a series of Electric BUS&COACH as well as Hydrogen fuel cell bus. There will always be a model that suits you the most.

Q: What can we offer?
A:

  • As a public transportation provider, we can not only provide you buses and coaches but also a comprehensive solution for a better travel experience.
  • Buses and coaches CBU, KD kit, Chassis and Body frames
  • Spare parts including various charger for EV


Q: Do you accept customized service?
A: Yes. We can offer customized service according to your requirements .

Q: What’s the delivery time?
A: Normally 20-35 workdays.

Q: Why choose us?
A: We guarantee professional service, competitive price with high quality vehicles.
