Place of Origin:
Chengdu, China
Brand Name:
ZEVAUTO
Certification:
ISO, PNS Class 2
Model Number:
CDL6730URDE
| Overall Specifications | Engine Specifications | ||
|---|---|---|---|
| Passenger Capacity | 40 (24+1 seats) | Manufacturer | Yuchai |
| Vehicle Size (mm) | 7310*2200*2900 | Model | YC4FA130-40 |
| Wheel Base (mm) | 3380 | Position | Rear |
| Front/Rear Overhang | 1740/2190 | Engine Type | 4 cylinders inline |
| Front/Rear Tread | 1850/1681 | Max Power (kw/rpm) | 95 |
| Approach/Departure (°) | 8/8 | Max Torque (N.m/rpm) | 340 |
| Max Grade-ability (%) | ≥20% | Displacement (L) | 2.982 |
| Top Speed (km/h) | 69 | Fuel | Diesel |
| Curb Weight (kg) | 6000 | Emission | Euro IV |
| Gross Weight (kg) | 8700 | ||
| Component | Specifications | Remarks |
|---|---|---|
| Front Axle | DANA 3.5T | |
| Rear Axle | DANA 5.5T | |
| Transmission | Manual 5 gears | |
| Suspension | Leaf spring | |
| Steering | Integral power steering, electro-hydraulic power steering | |
| Braking | Front disc and rear drum; dual circuit air brake, ABS, slack adjuster | |
| Tyre | 215/75R17.5 steel rim Tubeless radial tire | |
| Battery | Maintenance-free type |
| Feature | Specifications |
|---|---|
| AC | 14000kcal/h |
| Defroster | Yes |
| Instrument | Bus instrument, English system |
| Audio-system | MP5 |
| Lights | Front and rear combination light. Fog light. Inner dome light, step light. |
| Monitoring System | CCTV system with 6 cameras |
| Route Board | Front LED type |
| Component | Specifications |
|---|---|
| Body | 2 steps-entrance |
| Passenger Door | Front and middle aluminum inner swing door |
| Window | Sliding side window, laminated front windscreen and tempered rear-shield |
| Passenger Seat | 24 plastic city bus seats |
| Interior | PVC duct, PVC composite side plate. Punched aluminum-plastic roof plate. |
| Floor and Floor Cover | PVC floor, anti-slippery, flame retardant leather |
| Paint | Solid paint |
| Additional Features | Station broadcaster with speaker, wireless passengers stop buttons, Safety hammer with alarm function, Electronic clock, Manual fire extinguisher, Auto fire extinguisher in engine cabin, USB connector at driver area, reserved connector for payment machine, WIFI, Travelling record with GPS |
