Place of Origin:
Chengdu, China
Brand Name:
ZEVAUTO
Certification:
ISO
Model Number:
CDL6600URBEV
| Specification | Details |
|---|---|
| Vehicle Size | 6605 * 2200 * 2925 mm |
| Wheel Base | 2840 mm |
| Front/Rear Overhang | 1745/1425 mm |
| Front/Rear Tread | 1865/1600 mm |
| Approach/Departure Angle | 11°/15° |
| Max. Gradeability | ≥20% |
| Top Speed | 69 km/h |
| Curb Weight | 5000 kg |
| Gross Weight | 8500 kg |
| Passenger Capacity | 35 (10-16 seats) |
| Component | Specifications |
|---|---|
| Motor Manufacturer | ZEV |
| Max. Power | 110 kW/rpm |
| Max. Torque | 750 N.m/rpm |
| Battery Type | 95.25 kWh LiFePo4 |
| Cruising Range | ≥180 km |
| Charging Time | Within 2 hours |
| Component | Specifications |
|---|---|
| Front Axle | DANA |
| Rear Axle | DANA |
| Transmission | Auto transmission |
| Suspension | Leaf spring |
| Steering | Integral power steering, electro-hydraulic power steering |
| Braking | Front disc and rear drum; dual circuit air brake, ABS, slack adjuster |
| Tyre | 215/75R17.5 steel rim tubeless radial tire |
| Feature | Specifications |
|---|---|
| Air Conditioning | 12000 kcal/h |
| Defroster | Electric |
| Instrument | CAN Bus Line |
| Audio System | MP5 |
| Lighting | Front and rear combination light, fog light, LED through type inner dome light, step light |
| Monitoring System | CCTV system with 6 cameras |
| Route Board | Front, rear and side LED type |
| Component | Specifications |
|---|---|
| Body | Cathode coating |
| Passenger Door | Front aluminum inner swing door |
| Windows | Sliding side window, laminated front windscreen and tempered rear-shield |
| Passenger Seats | 10-16 plastic city bus seats |
| Interior | PVC duct, PVC composite side plate, punched aluminum-plastic roof plate |
| Floor Covering | PVC floor, anti-slippery, flame retardant leather |
| Paint | Solid paint |
| Additional Features | Station broadcaster with speaker, wireless passenger stop buttons, safety hammer with alarm function, electronic clock, manual fire extinguisher, auto fire extinguisher in battery cabin, USB connector at driver area, wire connector for payment machine, WiFi, travelling record with GPS |
