Name: 27-Seat Hydrogen Fuel Cell City Bus 10.5m LHD Zero Emission
Brand: Zhongzhi First Bus Chengdu Co., Ltd.
SKU: SPK6101FCEVG
Price: 250,000.00 USD
Availability: InStock

Home > products > Hydrogen Fuel Cell Bus >

27-Seat Hydrogen Fuel Cell City Bus 10.5m LHD Zero Emission

27 Seats Hydrogen Fuel Cell Bus LHD

elec city fuel cell bus 0 Emission

elec city fuel cell bus LHD

Place of Origin:

Chengdu, China

Brand Name:

ZEVAUTO

Certification:

ISO

Model Number:

SPK6101FCEVG

Request A Quote

Product Details

Product Name:

Hydogen Fuel Cell City Bus

Keyword:

Green Travel Bus

Vehicle Size:

10485×2500×3430

Passenger Capacity:

Motor Power:

140

Motor Torque:

1100

Battery Capacity:

52.99

Cylinder Capacity:

140L*6

Fuel Feeding Time:

8-15min

Fuel Feeding Pressure:

20-35Mpa

Transmission:

Auto Transmission

Suspension:

Air Bag

Tyre:

275/70R22.5 18PR

Driving Range:

≥350km

Gross Weight (kg):

16500

Highlight:

27 Seats Hydrogen Fuel Cell Bus LHD

elec city fuel cell bus 0 Emission

elec city fuel cell bus LHD

Payment & Shipping Terms

Minimum Order Quantity

Price

USD 200000-300000 per unit

Packaging Details

nude packing

Delivery Time

25 working days

Supply Ability

25000 units/per year

ZEV 10.5m 27 Seats Zero Emission Hydrogen Fuel Cell Bus Coach LHD

Get Best Price

video

ZEV 10.5m Hydogen Fuel Cell City Bus Driving Range 350km

Get Best Price

video

10.5m 27 Seats Electric Hydrogen Fuel Cell Bus LHD Zero Emission

Get Best Price

+8613608032908

jolin@zevauto.com

Contact Now

Product Description

Green Travel 10.5m 27 Seats Hydrogen Fuel Cell City Bus LHD Zero Emission

Green Travel 10.5m 27 Seats 0 Emission Hydrogen Fuel Cell City Bus LHD

Hydrogen Fuel Cell City Bus Series Advantages:

Environmental Protection: Energy conversion rate reaches 53%-55%, three times the thermal efficiency of ordinary internal combustion engines. Only produces electricity, heat and water - zero emissions and zero pollution.
Long Driving Range: Hydrogen refueling takes only 10-15 minutes with a driving range over 400km under full load conditions.
Convenient Operation: Features ergonomic central console, visual CAN bus instrument, and humanized buttons for easy operation.
Safe and Reliable: Industry-leading high-performance fuel cell battery power system and electric drive system. Low temperature start capability ensures trouble-free driving experience.

Technical Specifications

Overall Specifications		Passenger Capacity	79/18-27	Motor/Battery Specs
Vehicle size (mm)	1048525003430	Max.power(kw/rpm)	140	Max. torque (N.m/rpm)	1100
Wheel base (mm)	5800	Battery capacity	52.99
Front/Rear overhang	2235/2450			Hydrogen fuel-cell system
Front/Rear tread	2098/1870	Fuel cell Max power(kw)	42	Cylinder capacity (L)	140L*6
Approach/Departure(º)	7/8	Gas capacity in weight(kg)	20.1	Fuel feeding time(min)	8-15
Max. Grade-ability(%)	≥20%	Fuel feeding pressure(MPA)	20-35
Top speed (km/h)	69km/h
Curb weight (kg)	11150
Gross weight (kg)	16500

Item	Specs	Remarks
Chassis	Front axle: DANA Rear axle: DANA
Transmission	Auto transmission
Suspension	Air bag
Steering	Integral power steering, elector-hydraulic power steering
Braking	Front disc and rear drum; dual circuit air brake, WABCO ABS, slack adjuster
Tyre	275/70R22.5 18PR steel rim Tubeless radial tire
Battery	Maintenance-free type
Electronics	AC: 22000kcal/h Defroster: Electric defroster Instrument: Bus instrument, English system Audio-system: MP5 TV Lights: Front and rear combination light, Fog light Monitoring system: CCTV system with 5 cameras
Bus facilities	Body: Monocoque Passenger door: Front and middle aluminum swing door Window: Sliding side window, laminated front windscreen and tempered rear-shield Passenger seat: 26 passenger seats Interior: PVC duct, PVC composite side plate Floor and floor cover: PVC floor, anti-slippery, flame retardant leather Paint: Solid paint
Others	Safety hammer with alarm function, Electronic clock, Manual fire distinguisher, Auto fire distinguisher in engine cabin, USB connector at driver area, wire connector for payment machine and WIFI, travel record with GPS

Frequently Asked Questions

Q: Who we are?

A: ZEV is a group company specializing in buses and coaches R&D, manufacturing and marketing. From its foundation in 2000's, ZEV's culture of continuous innovation has made it a leading manufacturer in China. We have developed a series of Electric BUS&COACH as well as Hydrogen fuel cell buses, with models to suit various requirements.

Q: What can we offer?

As a public transportation provider, we offer complete bus/coach solutions along with comprehensive travel experience solutions.
Buses and coaches in CBU, KD kit, chassis and body frame configurations.
Spare parts including various chargers for electric vehicles.

Q: Do you accept customized service?

A: Yes, we provide customized services according to customer requirements.

Q: What's the delivery time?

A: Normally 20-35 workdays.

Q: Why choose us?

A: We guarantee professional service, competitive pricing, and high quality vehicles.
