Place of Origin:
Chengdu, China
Brand Name:
ZEVAUTO
Certification:
ISO, PNS Class 2
Model Number:
CDL6730URDE
| Parameter | Specification |
|---|---|
| Vehicle Size | 7310 * 2200 * 2900 mm |
| Wheel Base | 3380 mm |
| Front/Rear Overhang | 1740/2190 mm |
| Front/Rear Tread | 1850/1681 mm |
| Approach/Departure Angle | 8°/8° |
| Max Gradeability | ≥20% |
| Top Speed | 69 km/h |
| Curb Weight | 6000 kg |
| Gross Weight | 8700 kg |
| Passenger Capacity | 40 persons (24+1 seats) |
| Parameter | Specification |
|---|---|
| Manufacturer | Yuchai |
| Model | YC4FA130-40 |
| Position | Rear |
| Engine Type | 4 Cylinders Inline |
| Max Power | 95 kW |
| Max Torque | 340 N.m |
| Displacement | 2.982 L |
| Fuel Type | Diesel |
| Emission Standard | IV |
| Component | Specification |
|---|---|
| Front Axle | DANA 3.5T |
| Rear Axle | DANA 5.5T |
| Transmission | Manual 5 Gears |
| Suspension | Leaf Spring |
| Steering | Integral Power Steering, Electro-Hydraulic Power Steering |
| Braking System | Front Disc and Rear Drum; Dual Circuit Air Brake, ABS, Slack Adjuster |
| Tyre | 215/75R17.5 Steel Rim Tubeless Radial Tire |
| Battery | Maintenance-Free Type |
| Feature | Specification |
|---|---|
| Air Conditioning | 14000 kcal/h |
| Defroster | Yes |
| Instrument | Bus Instrument, English System |
| Audio System | MP5 |
| Lighting | Front and Rear Combination Light, Fog Light, Inner Dome Light, Step Light |
| Monitoring System | CCTV System with 6 Cameras |
| Route Board | Front LED Type |
| Feature | Specification |
|---|---|
| Body | 2 Steps Entrance |
| Passenger Door | Front and Middle Aluminum Inner Swing Door |
| Window | Sliding Side Window, Laminated Front Windscreen and Tempered Rear-Shield |
| Passenger Seat | 24 Plastic City Bus Seats |
| Interior | PVC Duct, PVC Composite Side Plate, Punched Aluminum-Plastic Roof Plate |
| Floor and Floor Cover | PVC Floor, Anti-Slippery, Flame Retardant Leather |
| Paint | Solid Paint |
| Additional Features | Station Broadcaster with Speaker, Wireless Passengers Stop Buttons, Safety Hammer with Alarm Function, Electronic Clock, Manual Fire Extinguisher, Auto Fire Extinguisher in Engine Cabin, USB Connector at Driver Area, Reserved Connector for Payment Machine, WIFI, Traveling Record with GPS |
