Place of Origin:
Chengdu, China
Brand Name:
ZEVAUTO
Certification:
ISO
Model Number:
CDL6121URBEV
| Overall Length | 12,000 mm |
|---|---|
| Width * Height | 2,550 mm * 3,225 mm |
| Passenger Capacity | 94 passengers / 22-46 seats |
| Wheel Base | 6,200 mm |
| Front/Rear Overhang | 2,700 mm / 3,100 mm |
| Curb Weight / Gross Weight | 11,800 kg / 18,000 kg |
| Top Speed | 69 km/h |
| Max Gradeability | 15% |
| Motor Manufacturer | ZEV |
|---|---|
| Max Power | 240 kW |
| Max Torque | 2,800 N.m |
| Battery Type | 350.07 kWh LiFePo4, water cooled with monitoring system |
| Charging Options | Single or double charging holder - Full charge: 3.1h (single) / 1.6h (double) |
| Driving Range | 280-650 km |
| Front Axle | 7.5T |
|---|---|
| Rear Axle | 13T |
| Transmission | Automatic |
| Suspension | Import air suspension, SACHS shock absorber ECAS |
| Steering | 8098 steering system |
| Braking | KNORR brake system, disc brake, maintenance-free |
| Tires | 275/70R22.5 aluminum rim |
| Air Conditioning | 32,000 kcal/h with air purifier |
|---|---|
| Defroster | Electric heater, 4 PTC radiators |
| Instrument Panel | CAN BUS line, LCD instrument |
| Audio System | 2 LCD displays |
| Lighting | LED combination lights |
| Monitoring | CCTV system with 10 cameras |
| Route Display | Front, rear and side LCD screens |
| Body Construction | Electro coating |
|---|---|
| Passenger Doors | Front aluminum inner swing door |
| Windows | Sliding side windows, laminated front windscreen, tempered rear shield |
| Seating | 28 plastic city bus seats with cushion |
| Interior Materials | Aluminum-plastic composite |
| Flooring | PVC anti-slip, flame retardant leather |
| Paint | Solid paint finish |
