Electric Mini Bus Buses For Eco-Friendly Transportation 6.6m Battery 122.2 Kwh
Product Description:
Electric Mini Buses are pure electric buses designed for city transportation, boasting a wide range of benefits compared to traditional vehicles. These EV minibuses offer a convenient, efficient, and cost-effective transportation solution, with a maximum seating capacity of up to 35 passengers (10-16 seats). They are equipped with a high-performance electric motor and battery pack, allowing for rapid charging times of within 2 hours. With its compact size, these electric mini buses are highly maneuverable and can be adapted to both left-hand drive (LHD) and right-hand drive (RHD) configurations, making them ideal for use in urban areas. This state-of-the-art electric city bus is a reliable, eco-friendly, and cost-effective option for transportation in cities.
Features:
- Product Name: Electric Mini Buses
- Safety Rating: 5 Stars
- Type: Bus
- Top speed (km/h): 69km/h
- Warranty: 3 Years
- Colors: Customized
- Keywords: Pure Electric Bus, Electric Mini Bus, EV Minibus
Technical Parameters:
| Overall specs |
Passenger capacity |
35 (23 seats) |
Motor specs |
Manufacturer |
ZEV |
| Vehicle size (mm) |
6630*2200*2950 |
Model |
-- |
| Wheel base (mm) |
3300 |
Position |
rear |
| Front/Rear overhang |
1755/1575 |
Engine type |
PMSM |
| Front/Rear tread |
1865/1632 |
Max.power(kw/rpm) |
100 |
| Approach/Departure(º) |
12/13 |
Max. torque (N.m/rpm) |
1000 |
| Max. Grade-ability(%) |
≥15% |
Displacement(L) |
-- |
| Top speed (km/h) |
69km/h |
Fuel |
Electric |
| Curb weight (kg) |
5600 |
Emission |
-- |
| Gross weight (kg) |
8500 |
|
| |
Battery |
122.2 kwh,LiFePo4, water cool. |
| |
Item |
Specs |
Remarks |
| Chassis |
Front axle |
DANA 3.5T |
|
| Rear axle |
DANA 5.5T |
|
| Transmission |
Auto transmission |
|
| Suspension |
Leaf spring |
|
| Steering |
Integral power steering, elector-hydraulic power steering |
|
| Braking |
Front disc and rear drum ; dual circuit air brake, ABS,slack adjuster |
|
| Tyre |
215/75R17.5 steel rim Tubeless radial tire |
|
| Battery |
Maintenance-free type |
|
| electronics |
AC |
13000kcal/h |
|
| Defroster |
Natural air blow type |
|
| Instrument |
Bus instrument, English system |
|
| Audio-system |
MP5 |
|
| Lights |
Front and rear combination light. Fog light, inner dome light, step light. |
|
| Monitoring system |
CCTV system with 5 cameras |
|
| Route board |
Front LED type |
|
| Bus facilities |
Body |
2-step entrance |
|
| Passenger door |
Front aluminum inner swing door |
|
| Window |
Sliding side window, laminated front windscreen and tempered rear-shield |
|
| Passenger seat |
23 plastic city bus seats with cushion |
|
| Interior |
PVC duct, PVC composite side plate.
Punched aluminum-plastic roof plate.
|
|
| Floor and floor cover |
PVC floor, anti-slippery, flame retardant leather |
|
| Paint |
Solid paint |
|
| Others |
Station broadcaster with speaker, wireless passengers stop buttons, Safety hammer with alarm function,Electronic clock,Manual fire distinguisher ,Auto fire distinguisher in battery cabin,USB connector at driver area,reserved connector for payment machine,WIFI , Travelling record with GPS |
|
Applications:
ZEVAUTO Electric Mini Buses – Zero Emission & Pure Electric with 35 Seats
ZEVAUTO electric mini buses are designed as zero emission and pure electric buses with a seating capacity of 35 passengers. The mini buses are manufactured in Chengdu, China, and have received the ISO certification. The buses offer a comfortable and smooth ride, and have a mini size with a charging time of only two hours. The electric mini buses are powered by energy-efficient electric fuel, making them an ideal choice for short-distance travel.
ZEVAUTO electric mini buses are an ideal choice for city transportation, as they provide a safe, clean and convenient way for passengers to travel. They are particularly suitable for commuting, sightseeing, airport transfers, and other short distance trips. The buses are also suitable for small communities, schools, and universities, as well as for tourism and sightseeing.
With a seating capacity of 35 passengers, the electric mini buses from ZEVAUTO provide a comfortable and reliable way to travel for both passengers and drivers. The mini buses are designed with a lightweight construction and offer excellent maneuverability, making them a perfect choice for small towns and cities. Additionally, the buses are equipped with advanced safety features, such as anti-lock brakes, airbags, and other advanced safety systems.
ZEVAUTO electric mini buses are a great choice for those seeking a reliable and safe transport option. The buses are energy-efficient, and their mini size makes them perfect for small-scale transportation. Furthermore, the buses come with a two-hour charging time, making them a convenient and economical option for short-distance travel.
Customization:
Customized Electric Mini Buses from ZEVAUTO (Chengdu, China)
- Certified by ISO
- Zero emission
- Left-Hand Drive and Right-Hand Drive
- Fast Charging Time within 2 hours
- Seating capacity from 10 to 16 seats
- Pure Electric Power Source
ZEVAUTO's electric mini buses provide a perfect solution for zero emission transportation. With our customized electric mini buses, you can enjoy fast charging time and a comfortable ride for up to 16 passengers.
Support and Services:
Electric Mini Buses Technical Support and Services
At Electric Mini Buses, we provide comprehensive technical support and services to help you get the most out of your electric mini bus. Here are some of the technical support and services we provide:
- Troubleshooting assistance for hardware and software issues
- Operating system updates and installation
- Accessory and device installation
- Online chat and phone support
- Free training and tutorials
We also offer expert repairs and maintenance for your electric mini bus. Our technicians are available 24/7 to help you with any issue you may be having. Contact us today to learn more about our technical support and services.
Packing and Shipping:
Packaging and Shipping of Electric Mini Buses
Electric Mini Buses are packaged and shipped in wooden crates, with foam cushioning and shrink wrap to protect the product during transit. The wooden crate is designed to be sturdy and secure, and can be easily lifted by forklifts from the shipping docks. The crate is also waterproof, so the product will remain protected even if it is exposed to rain or moisture during shipping.
The Electric Mini Bus will be shipped via ground or air freight, depending on the customer's preference. For ground freight, the shipping time is typically 1-2 weeks, and for air freight, the shipping time is usually 1-3 days. Customers can also track their shipment in real time using the tracking number provided by the courier.
In order to ensure a safe and secure delivery, all Electric Mini Buses are thoroughly inspected before being shipped out. If there are any issues, the customer will be contacted and the product will be re-inspected to ensure a safe delivery.
FAQ:
Q: What is the brand name of the Electric Mini Buses?
A: The brand name of the Electric Mini Buses is ZEVAUTO.
Q: Where are Electric Mini Buses manufactured?
A: Electric Mini Buses are manufactured in Chengdu, China.
Q: Are Electric Mini Buses certified?
A: Yes, Electric Mini Buses are certified by ISO.
Q: What is the range of Electric Mini Buses?
A: The range of Electric Mini Buses depends on the type and model. It can be up to 150km.
Q: What is the charging time of Electric Mini Buses?
A: The charging time of Electric Mini Buses depends on the type and model. Generally, it takes about 6-8 hours.
